QMI StormSafe® Security Screens

Description

QMI StormSafe® Hurricane & Security Screens are far more than just upgraded bug screens; they’re a state-of-the-art protective barrier for your home. Made with nearly impenetrable stainless steel mesh, these screens not only prevent burglars and flying storm debris from breaking your windows but also allow natural airflow and light into your home, offering 24/7/365 protection without making your residence look boarded up. The screens have undergone rigorous testing, including simulated knife attacks, large missile hurricane tests, dynamic impact tests, and jimmy tests, to simulate crowbar forced-entry, and have been approved by both the Florida Building Code (FBC) and Miami-Dade (HVHZ).

Beyond just security, these screens come with a myriad of additional benefits. They keep out bugs, lizards, and alligators, while also allowing for proper ventilation and clear exterior views. Energy-saving features reduce the heat load on your home, and the screen material is designed to maximize visual acuity by being black in color. Their low-profile frames, measuring just 2-7/16” (61.9 mm) wide x 1-1/8” (28.6 mm) deep, blend seamlessly with existing architecture, and specialized egress screens provide a simple panic bar for easy emergency exits.

Built to withstand Category 5 hurricane conditions, the screens significantly reduce the risk of glass breakage from flying debris. They maintain the benefits of ordinary bug screens by allowing light breezes and ventilation. Aesthetically, they make no compromises, with the visual clarity being nearly identical to that of ordinary screens. The screen frames are unobtrusive, able to be custom-tailored to fit any architectural need, from arches to polygons to other specialty shapes. They also offer UV and sun protection, shading up to 22% of sunlight without compromising on the view and reducing UV rays by up to 60%, thereby protecting your interior furnishings.

In summary, QMI’s Hurricane & Security Screens offer an unmatched combination of safety, aesthetic design, and functional benefits. Whether it’s deterring potential intruders, protecting against hurricanes, or simply keeping out pests, these screens serve multiple purposes without sacrificing design or visual appeal.

QMI – Security Screen

Additional information

Design Options

Panel Styles

Colors

Construction

Qompact Shutters: The Gold Standard in Shutter Technology

Size and Design

Smaller Shutter Box

The Qompact shutter system features an ultra-compact design, with a shutter box that is 40-50% smaller than traditional systems. For a 122” (3.1 m) tall shutter, for instance, only a 6.5” (165 mm) box is required, maximizing space efficiency.

Comparison of Box Sizes by Shutter Height

– 69” (1700 mm) : Qompact 5.5” (140 mm), Others 8” (200 mm)
– 84” (2100 mm) : Qompact 6” (150 mm), Others 10” (250 mm)
– 122” (3000 mm) : Qompact 6.5” (165 mm), Others 12” (300 mm)
– 149” (3800 mm) : Qompact 7” (180 mm), Others 12” (300 mm)
– 184” (4800 mm) : Qompact 8” (205 mm), Others 14” (350 mm)

Elegant Slat Design

The Qompact system comes with 10 different slat sizes that have been ingeniously engineered to nest tightly together, allowing for an incredibly compact roll and a smaller box housing.

Strength and Durability

Unparalleled Hinge Strength

Qompact’s slat hinges are robust enough to support curtains up to 6 meters wide (20 feet) and 5 meters high (15 feet). They are 27-times stronger than foam-filled variants, significantly enhancing the shutter’s strength.

Impact Resistance

In rigorous impact testing, Qompact shutters have shown remarkable resilience, withstanding 82 punches, 5 kicks, and 80 hits with a sledgehammer. They consistently outperform foam-filled competitors.

Pull-Apart Strength

The pull-apart strength of Qompact is a staggering 8050 kg/m, making it immensely stronger than the 296 kg/m of 40mm perforated slip hinges.

Insulation and Efficiency

Qompact shutters built into wall applications can feature 30-40% more shutter box foam insulation than traditional systems, enhancing energy efficiency.

Versatility

Residential Applications

For homeowners, Qompact offers quiet operation, elegant design, and robust security. These shutters also provide privacy, sun shading, and even hurricane protection.

Commercial Applications

In the commercial setting, Qompact shutters are unmatched, capable of being built both wider and taller than foam-filled counterparts. Widely used in the United States, these shutters serve both loss prevention and design needs and can even be perforated for nighttime merchandising.

Safety Standards

Meeting the strict U.S. Florida (FBC) hurricane standards, Qompact shutters can withstand winds of up to 330 km/h (200 mph) for spans as wide as 6000mm (19.5 ft).
